Section 4 Configure

Security

Button

Security

Link

Passwords

Description

The Security features are available by clicking on the Security toolbar

button. Some items of this category do not appear when you log on as

User.

Response

Description

Access to your Gateway is controlled through two user accounts,

Admin and User. When you ﬁrst power up your Gateway, you create a

password for the Admin account. The User account does not exist by

default. As the Admin, a password for the User account can be entered

or existing passwords changed.
